LiteDimmer Plus DC100V, 100W, DC Unit, V-Mount
US $649.00
LiteDimmer+ Plus DC100V is the ideal portable companion for powering +Series fixtures. With a focus on DC input power, the 100W unit can be powered using typical V-Mount-compatible batteries. LiteDimmer+ Plus DC100V is compatible with LiteMat+ Plus 1, 2, and 2L.
LiteDimmer+ Plus DC100V is the ideal portable companion for powering +Series fixtures. With a focus on DC input power, the 100W unit can be powered using typical V-Mount-compatible batteries. Optionally, an external AC powered, 12 volt power supply can be used and attached to the battery mount with the optional power supply mounting plate. The LiteDimmer+ Plus’ rugged housing includes several different mounting options including four 1/4-20 threads for attaching clamps or brackets.
POWER RATING: 100W
VOLTAGE INPUT (BATTERY): 14.4VDC Nominal (10~16VDC) (V-Mount)
VOLTAGE INPUT (EXTERNAL): 9~40VDC (PL4 Connector) (Pins 1 and 4 – Neg., Pins 2 and 3 + Pos.)
VOLTAGE OUTPUT: 24VDC Constant Voltage, PWM (PL7 Connector)
TRIGGER JACK: 2.5 mm TRS
DIMMING RANGE: 0% to 100% Continuous, Flicker-Free
CONTROLS: On-Board “ON-OFF” Switch, Manual Kelvin Dial, Manual Dimming Dial
SOFTWARE INTERFACE: Proprietary Connector, Service Center Upgradeable
MOUNTING: (4) 1/4-20 Threaded Inserts, Drywall Screw Holes, Velcro®/Cable Tie Slots, Paracord Lanyard
AMBIENT TEMP. OPERATION: –10° to +50° C (14° to 122° F)
IP RATING: IP20
LiteDimmer Plus DC100V Data Sheet
LiteDimmer Plus DC100 - 200 User Guide
LiteDimmer Plus DC100 - 200 Quick Start Guide
