LiteMat Plus 2L Kit with LiteDimmer Plus (Non-DMX)

LiteMat Plus 2L is a lightweight LED lighting fixture system designed for cinema, television, and HD video. By providing evenly spaced, color-correct LEDs spread out over a large area, LiteMat creates soft light without requiring diffusion. The “soft-through-pixelization” method allows the unit to achieve bright light levels while remaining 0.9 in. (23 mm) thick in size and 3.8 lb (1.72 kg) in weight.

• LiteMat Plus 2L Head
• LiteDimmer Plus 100W
• LiteMat 2L Full Diffuser
• LiteMat 2L Half Diffuser
• LiteMat 2L Quarter Diffuser
• LiteMat 2L PolySkirt
• LiteMat 2L Parasquare Louver
• PL7 Cable, 12 ft.
• kMount
• LiteMat 2L KitBag

Power: 100W
Voltage: 24VDC
Current: 4.17A
LED Qty: 1152
Weight: 3.8 lbs (1.72 kg)
Height: 11.5 in. (292 mm)
Width: 40 in. (1016 mm)
Length: .9 in. (23 mm)

LiteMat Plus 2L Data SheetLiteMat Plus Catalog
LiteMat Plus, LiteTile Plus, and Legacy Library Vectorworks 2021
